INSTRUCTIONS ARE IN PDF FILE (ENGLISH). A LINK TO THE INSTRUCTIONS CAN BE FOUND IN THE INVOICE.

Please be aware this lighting kit requires some skills and knowledge of soldering as it is in kit form. That includes any circuit boards.  But the instructions do tell you how they go together.
I will not be held responsible for errors made in wiring of the model (but If you are unsure get in touch and I will help as best as I can or use the net for help).

PLEASE MAKE SURE YOU READ THE DESCRIPTION SO YOU KNOW WHAT YOU ARE BUYING AS I DO NOT ACCEPT CANCELLATIONS

Contents of lighting kit:

9 x 3mm White LEDs.
1 x 2mm White Top Hat LED.
4 X 3mm Red LEDs.
2 x 5mm Red LEDs.
1 x 2mm Red Top Hat LED.
2 x 3mm Green LEDs.
4 x 3 LED White Strips (25mm long).
14 x 3 LED White Strips (50mm long).
2 x 12 LED Blue Strips (25mm long).
10 x 470ohm Resistors.
1 x Flashing Circuit Kit.
Cable x 4 Colours.
Shrink Tube.
2 x JST Connectors, Male/Female.
0.75 Dia Fibre Optic.

This lighting kit requires some skills and knowledge of electronics and soldering as it is in kit form.
I will not be held responsible for errors made in wiring of the model (but If you are unsure get in touch and I will help as best as I can or use the net for help).

Notes: The item is only suitable for indoor use.
Choking hazard – small parts. Not suitable for children under 3 .
Do not look directly into the LEDs, it could damage the retina.
Instructions and pictures are my property and may not be published.
